Contactless car wash machine
|
|
|
|
| |
Item | Specifications ＆ Functions | ||||
Model | S7 | S11 | S11 Pro | S11S | T5S |
Price(Fob Qingdao) | $11,800 | $14,800 | $15,800 | $18,800 | $19800 |
Installation size(L*W*H) | 6500*3500*3200mm | 7000*3500*3200mm | 7000*3500*3200mm | 7500*3500*3200mm | 10000*4000*3200mm |
Water pump motor power | 15KW German Pinford high-pressure water system | 15KW German Pinford high-pressure water system | 15KW German Pinford high-pressure water system | 18.5KW German Maestron high-pressure water system | 18.5KW German Maestron high-pressure water system |
Max. Wash height | 2050mm(Customizable) | 2050mm(Customizable) | 2050mm(Customizable) | 2050mm(Customizable) | 2050mm |
Max. Wash width | 2200mm(Customizable) | 2200mm(Customizable) | 2200mm(Customizable) | 2200mm(Customizable) | 2200mm |
Max. Wash length | 5900mm(Customizable) | 5900mm(Customizable) | 5900mm(Customizable) | 5900mm(Customizable) | 5900mm |
Washing speed | 3-6 min.(depend on the operation mode or procedure set ) | 3-8 min.(depend on the operation mode or procedure set ) | 3-8 min.(depend on the operation mode or procedure set ) | 3-8 min.(depend on the operation mode or procedure set ) | 3-8 min.(depend on the operation mode or procedure set ) |
Total weight | 1500kg | 2300kg | 2300kg | 2600kg | 2500kg |
Power supply | 380V/17kw | 380V/22kw | 380V/22kw | 380V/22kw | 380V/22kw |
Air dryer power | 5.5kw*4 sets frequency control | 5.5kw*4 sets frequency control | 5.5kw*6 sets frequency control | 5.5kw*4 sets frequency control | 5.5kw*6 sets frequency control |
Water Consumption | 80-120L/car | 80-120L/car | 80-120L/car | 80-120L/car | 80-200L/car |
Flushing pressure | 100kg | 150kg | 150kg | 150kg | 150kg |
Electricity consumption | 0.4-1kw•H/car | 0.5-1.2kw•H/car | 0.5-1.2kw•H/car | 0.5-1.2kw•H/car | 0.5-1.2kw•H/car |
Packing | ≈8CBM | ≈11CBM | ≈11CBM | ≈12CBM | ≈11CBM |
Function | Chassis washing | Chassis washing | Chassis washing | Chassis washing | Chassis washing |
Wheel and side door flush | Wheel and side door flush | Wheel and side door flush | Wheel and side door flush | Wheel washing | |
high pressure surround flushing | high pressure surround flushing | high pressure surround flushing | high pressure surround flushing | High pressure swing flushing | |
snow foam | snow foam | snow foam | snow foam | Fine Penetrating Foam | |
car washing liquid Automatic proportioning system | car washing liquid Automatic proportioning system | car washing liquid Automatic proportioning system | car washing liquid Automatic proportioning system | car washing liquid Automatic proportioning system | |
Non-resistance slide frame | Non-resistance slide frame | Non-resistance slide frame | Non-resistance slide frame | Stainless steel plate body | |
LED indicator | LED large screen display | LED large screen display | LED large screen display | LED large screen display | |
7-inch touch screen | 7-inch touch screen | 7-inch touch screen | 10-inch touch screen | 10-inch touch screen | |
Water wax system | Water wax system | Water wax system | Water wax system | Water wax system | |
Mobile air drying 5.5KW*3 fans | Mobile air drying 5.5KW*4 fans | Mobile air drying 5.5KW*4 fans | Mobile air drying 5.5KW*4 fans | Mobile air drying 5.5KW*6 fans | |
Colorful Waterfall Maintenance | Colorful Waterfall Maintenance | Colorful Waterfall Maintenance | Profiling cleaning | ||
360 degree surround foam | 360 degree surround foam | 360 degree surround foam | Section flushing | ||
Pioneer of intelligent frequency conversion and energy saving | Pioneer of intelligent frequency conversion and energy saving | Pioneer of intelligent frequency conversion and energy saving | Pioneer of intelligent frequency conversion and energy saving | ||
ISPC flexible pressure regulation | SPC flexible pressure regulation | ISPC flexible pressure regulation | ISPC flexible pressure regulation | ||
3D monitoring and positioning | Independent wheel brush | ||||
CNC operation | |||||
Automatic adjustment of car wash width | Automatic adjustment of car washing height | ||||
The L-arm walks left and right more flexibly and runs faster | |||||
Remote control operation | Remote control operation | Remote control operation | Remote control operation | Remote control operation | |
Intelligent anti-collision | Intelligent anti-collision | Intelligent anti-collision | Intelligent anti-collision | Intelligent anti-collision | |
Security alarm system | Security alarm system | Security alarm system | Security alarm system | Security alarm system | |
Automatic standby function | Automatic standby function | Automatic standby function | Automatic standby function | Automatic standby function | |
Car wash quantity report statistics | Car wash quantity report statistics | Car wash quantity report statistics | Car wash quantity report statistics | Car wash quantity report statistics | |
Troubleshooting system | Troubleshooting system | Troubleshooting system | Troubleshooting system | Troubleshooting system | |
Optional | Colorful lights | Colorful lights | Colorful lights | Colorful lights | Colorful lights |
Water recycle system | Water recycle system | Water recycle system | Water recycle system | Water recycle system | |
Self-service payment system | Self-service payment system | Self-service payment system | Self-service payment system | Self-service payment system | |
Mobile remote control | Mobile remote control | Mobile remote control | Mobile remote control | Mobile remote control | |
Mobile phone monitoring function | Mobile phone monitoring function | Mobile phone monitoring function | Mobile phone monitoring function | Mobile phone monitoring function | |
Automatic door function | Automatic door function | Automatic door function | Automatic door function | Automatic door function | |
